12-63mm ppr pipe extruder machine / ppr pipe machine
1. PPR water pipe machine:
2. Pipe range:20mm-160mm
3. Production speed: 2-15m/min
4. Output: 60-200kg/h
PPR water pipe machinery:
Special single screw extruder for polyolefin, having high extruding velocity and effective plasticization.
Separation mixing screw specialized for polyolefin.
Producing pipe diameter range Φ20-Φ160mm up to 250mm, speed range from 0.8-15m/min
Could produce PE pipe changing into related calibration/forming/sizing sleeve for PE pipe.
Vacuum feeder→Main single screw extruder+marking line extruder→Mould→Vacuum calibration spraying cooling tank→Pedrail haul-off machine→Chipless cutter/blade cutter(option)→reversible stacker
Note:we also could produce two-layer PPR pipe
Marking line extruder
φ 20-63; φ 20-110
φ 63-160; φ 110-160
Haul off machine
1. Installation and test running
We will invite customers to check the machine before shipment. And if the customer requests us to guide installment and test running in his factory, we will send our engineer. And the customer should pay for engineer's ticket, visa, room and board, $80 per day for one people as allowance.
2. Quality guarantee
We normally guarantee machine quality for one year to key components of the machines, if key components of machine are broken for technical reason, we will replace it with new one free. (The customer should return broken components).
